VESTA-AR

• Rated Voltage: 5-15kV; 95kV BIL
• Current: 600-2000A; 31.5kA, 40kA, 50kA
• Dimensions / 1200A: 24” x 96” x 60”
• Dimensions / 2000A: 30” x 96” x 72”
• Magnetically actuated breaker – up to 100,000 operations
• Full front accessibility
• Draw out breaker, PT, CT & CPT
• Shortest breaker pole spacing between phases
• Front and rear viewing windows
• Epoxy insulated bus bar as standard
• Plenum design incorporated into structural configuration. No additional height requirement.
• UL & cUL listed; Type 2A and 2B in accordance with ANSI/IEEE standards

VESTA-AR fulfills the requirement for a modern switchgear assembly that makes efficient use of available floor space and minimizes the time required for inspection, repair and maintenance of equipment. IEM’s arc-resistant technology ensures a safe and reliable solution for maintenance personnel and facility in the event of an arc flash.

Front Accessibility
Full front accessibility for cable connections and current transformers (CT); this advanced design feature ensures ease of maintenance, minimal usage of floor space, and creates a safe environment.

Front & Rear Viewing Windows
Located on the front and rear of the assembly, these viewing casements allow complete access to viewing of the bus bar compartment for maintenance to assess any signs of overheating of the bus.

Insulated Bus Bar System
Medium Voltage insulating and support system with specialty designed structure for current transformers (CT’s). Epoxy insulated bus as standard.

Testing
KEMA-Powertest completed. Rigorous testing shows fully reinforced and sealed joints, hinges and latches, which reduce the risk of damage to maintenance personnel and other existing equipment in the event of an arc flash.

UL & cUL Listed, Meets or exceeds type 2A and 2B in accordance with ANSI/IEEE 37.20.7. and NEMA standards.
