IP2X Power Panel

IP2X Panelboards

IEM’s Low Voltage Freestanding Finger-Safe Panelboard is engineered with an IP2X rating to enhance worker safety and reduce risk of accidental contact with energized parts. Its robust design improves system reliability, helping facilities lower the chance of electrical outages that lead to costly downtime. Built for performance and protection, it delivers safe, dependable power distribution for demanding environments.

IP2X Construction (Finger Safe)
Ships fully assembled, ready to install
View thru door protection for all devices
Integrated top conduit support rack
Top & Bottom Cable Access (Main Lugs @ bottom)
Freestanding
Front Access Only
Seismic Qualified
Dimensions: 44”W x 20”D x 90”H
Finish: ANSI #61 Grey
Capacity: 1200 Amp
Input: Main Lugs - NEMA 2-Hole Provisions
Range of Protection Up to (4) 600AF & (10) 250AF MCCBs: 15 - 600A Trip Ratings
Short Circuit Current Rating
100kAIC @ 208VAC
65kAIC @ 480VAC
50kAIC @ 600VAC

UL 67 Certified Low Voltage Panelboard
UL Type 1 Enclosure Rating (Indoor)

Documentation

Product Sheets (PDF)

IP2X Power Panel Product Sheet

Download
