Metal-Clad Switchgear

Medium Voltage Metal-Clad Switchgear

IEM’s medium-voltage, vacuum circuit breaker product line is available in the 5kV, 15kV, 27kV, and 38kV classes in outdoor non-walk-in, outdoor walk-in and indoor power distribution enclosures. Selection of specific protective relays, metering devices and circuit breakers for specific applications is optional. This flexible and customizable feature makes IEM an ideal engineering and design choice for unique projects and for matching or upgrading existing installations.

Voltage: 2400V to 38kV
Ampacity: 600A to 3000A
Optimal component selection includes any commercially available vacuum circuit breakers from industry leading manufacturers
Rear access for load and incoming connections
Compartmentalized construction with breaker compartment for each device
One-high or two-high construction
Unit substation primaries
Indoor or Outdoor applications

IEM Switchgear meets or exceeds all ANSI, IEEE, and NEMA standards applicable to metal clad switchgear including C37.20, C37.20.2, C37.20.3, C37.55, C37.57, and NEMA SG-4.
NEMA 1 and NEMA 3R enclosures
