38kV Switchgear

Medium Voltage 38kV Switchgear

Now available in the 38kV class in indoor, outdoor non-walk-in, and outdoor walk-in enclosures; we offer optional component selection including different choices for protective relays, metering devices and PLC monitoring for specific power distribution applications. This customizable feature makes IEM a flexible and ideal choice for unique projects and for matching or upgrading existing installations. The 38kV mechanically complete switchgear rated for 40kA is also available with CSA listing when required and applicable, and meets also the seismic requirement of the UBC code.

Voltage: 38kV
Ampacity: 1200, 2000A
Basic Insulation Level (BIL): 150kV
Breaker interrupter ratings: Up to 40kV
Breaker interrupter rating: Up to 40 kA
NEMA 1: 42” W x 123” D x 95” H
NEMA 3R: 42” W x 132” D x 107” H
Advanced vacuum circuit breaker
Compartmentalized construction with breaker compartment for each device
Breaker & PT can be constructed into one section (feeder only)
Main-tie-main automatic transfer scheme
Rear access for load and incoming connections
Indoor and outdoor applications, non walk-in and walk-in enclosures available

IEEE C37.20.2
CSA C22.2 No. 31-M89
EEMAC G8-3.2 ANSI IEEE C37.04, C37.06, C37.09
ANSI IEEE C37.04, C37.06, C37.09
Seismic Compliance
